| NEW Innovation in Wire Decking!! Rectangular wire design provides 27% more strength. Unique Flared channel is formed to provide maximum strength and then welded for added integrity. Channel is Universal for Step, Box and Channel Beams. Finish is Zinc plated after welding to provide a clean rust resistant product. Rack Mat is ideal for pallet rack providing increased visibility and sprinkler effectiveness. May also reduce insurance costs. |
|
"RACK MAT"-Wire Decking |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Universal Flared Channel Decking for Step and Box Beams |
|
|
|
|
|
|
|
|
|
| Part |
D x W |
Capacity |
Channel |
# of |
Grid |
|
Weight |
| Number |
Decking Size |
Lbs. |
Style |
Channels |
Size |
Finish |
Lbs. |
| WD3634F-3-30 |
36 x 34 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
13 |
| |
|
|
|
|
|
|
|
| WD3646F-3-30 |
36 x 46 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
18 |
| |
|
|
|
|
|
|
|
| WD3652F-3-30 |
36 x 52 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
20 |
| |
|
|
|
|
|
|
|
| WD3658F-4-30 |
36 x 58 |
3000 |
Flare |
4 |
4.5in*2.5in |
Zinc |
23 |
| |
|
|
|
|
|
|
|
| WD4234F-3-25 |
42 x 34 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
15 |
| WD4234F-3-30 |
42 x 34 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
15 |
| |
|
|
|
|
|
|
|
| WD4246F-3-25 |
42 x 46 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
21 |
| WD4246F-3-30 |
42 x 46 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
21 |
| |
|
|
|
|
|
|
|
| WD4252F-3-25 |
42 x 52 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
23 |
| WD4252F-3-30 |
42 x 52 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
23 |
| |
|
|
|
|
|
|
|
| WD4258F-4-25 |
42 x 58 |
2500 |
Flare |
4 |
4.5in*2.5in |
Zinc |
27 |
| WD4258F-4-30 |
42 x 58 |
3000 |
Flare |
4 |
4.5in*2.5in |
Zinc |
27 |
| |
|
|
|
|
|
|
|
| WD4446-3-25 |
44x46 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
21 |
| |
|
|
|
|
|
|
|
| WD4452-3-25 |
44x52 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
23 |
| |
|
|
|
|
|
|
|
| WD4834F-3-25 |
48 x 34 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
18 |
| WD4834F-3-30 |
48 x 34 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
18 |
| |
|
|
|
|
|
|
|
| WD4846F-3-25 |
48 x 46 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
24 |
| WD4846F-3-30 |
48 x 46 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
24 |
| |
|
|
|
|
|
|
|
| WD4852F-3-25 |
48 x 52 |
2500 |
Flare |
3 |
4.5in*2.5in |
Zinc |
26 |
| WD4852F-3-30 |
48 x 52 |
3000 |
Flare |
3 |
4.5in*2.5in |
Zinc |
26 |
| |
|
|
|
|
|
|
|
| WD4858F-4-25 |
48 x 58 |
2500 |
Flare |
4 |
4.5in*2.5in |
Zinc |
30 |
| WD4858F-4-30 |
48 x 58 |
3000 |
Flare |
4 |
4.5in*2.5in |
Zinc |
30 |
|
|
|
|
|
|
|
|
| Note: Product ships from specific warehouse locations. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
This site is currently under construction.
To contact us, please call 1-877-CAYUGA-3 (229-8423) and ask for Todd.
|
|
